Ansys SIwave
La piattaforma specializzata per la caratterizzazione di schede PCB e ICs: Power&Signal Integrity, EMI/EMC
Ansys è un prodotto Ansys Inc.
Ansys è un prodotto Ansys Inc.
Slwave è una piattaforma di progettazione specializzata per la valutazione di Power Integrity, Signal Integrity, EMI/EMC, radiazione EM di circuiti integrati e schede PCB.
Slwave consente di importare i principali modelli geometrici MCAD ed ECAD come Altium, Autodesk, Cadence, Dassault, Mentor Graphics, PTC e Zuken. SIwave consente di modellare, simulare e validare canali di comunicazione ad alta velocità e di dimensionare i sistemi di distribuzione della potenza tipicamente presenti nei moderni dispositivi elettronici.
SIwave estrae accuratamente parametri per bus SERDES e memorie, garantendo la conformità alla specifica di prodotto. L’estrazione delle forme d’onda nelle reti di distribuzione della potenza (Power Distribution Network, PDN) e l’analisi automatica del disaccoppiamento consente di verificare i margini di rumore e garantire il rispetto dei profili di impedenza.
SIwave consente il calcolo e l’estrazione delle mappe di potenza e, tramite il link bidirezionale con il solutore di Icepak, di temperatura delle schede PCB e dei componenti.
