CASE STUDY

RecurDyn enables engineers to create full FE models of flexible belts

Faciliitates extraction of stresses and strains from entire structure and takes into account all friction forces, shape and misalignment dynamics and structural flexibility

A virtual prototype of a belt must necessarily include the high flexibility of the belt itself, as well as a detailed description of the contacts. This is another scenario where RecurDyn provides better functionality than its competitors.

CASE STUDY

Optimization of a brush cutter using knowledge-based engineering

This article describes how the company created and tested a process to construct a parametric CAD model capable of providing its designers with a starting point for any new machine to be designed.

CASE STUDY

Printer

RecurDyn offers a dedicated toolkit to pre-process, solve and post-process problems involving flexible media

The final portion of the paper path of a laser printer has been studied using the Media Transport Toolkit to evaluate the influence of the corrugating roller which is used to corrugate the sheet to keep it straight before falling into the tray.

CASE STUDY

Ensuring product innovation and lifetime product performance right from the design phase

Lovato Electrics chooses ANSYS MAXWELL to guarantee it brings superior products to market in less time

Lovato Electric is committed to delivering innovation through its products and so it commissioned EnginSoft to help it create a pilot project in order to compare and finally select an electromagnetic field simulation software solution.

CASE STUDY

Churning loss within a calender roll of a paper machine

Using Particleworks to investigate the churning loss in terms of the torque caused by the oil-piston interaction within a calender roll of a paper machine

Performing flow simulations to investigate the complex loss mechanisms caused by the interaction of the rotating oil ring within a piston in the inside of the roll of a calender, which is an important device of a paper machine. Hereby, the trends of the churning losses are determined for design improvement conducted by Voith Paper R&D.

CASE STUDY

Taking stock: the evolution of simulation around the world pre- and post-Covid-19

From its earliest days through to future post-pandemic perspectives

At this particular moment in time, this article wishes to reflect on the evolution of CAE and simulation in an effort to present a big-picture view when most of us are daily dealing with all the devil in the details in every aspect of our lives. We approached some long-standing business friends in engineering simulation from various regions around the world to help us in this task

CASE STUDY

Earthquake evaluation of a stacker crane deployed in the Mexican Republic

The intralogistics sector uses stacker cranes to transport stacked pallets between racks

Stacker cranes handle pallet placement in the warehouse, moving longitudinally along the aisles between the warehouse shelves to deposit and retrieve loads. Stacker cranes are susceptible to earthquakes that can damage them and the racks around them.

CASE STUDY

Advanced strategies for the flow field optimization of a medical device

How to use a hybrid method of CFD analysis for product optimization and performance improvement while reducing the computational effort and the time required to achieve the results

Further reduction of the heat loss compared to the best design of the NSGA-II first phase design optimization: a further 4% gained

CASE STUDY

Lubrication and heat dissipation in transmissions and bearings

Lubrication and heat dissipation in transmissions and bearings are critical to both the performance and the life of these systems

Transmission design is mainly based on the mechanical aspects of the transmission and lubrication is an aspect that is verified, and eventually corrected, based on bench testing, i.e. once the design phase has been completed and a physical prototype is available.

CASE STUDY

Numerical simulations for the structural performance assessments: a connecting rod’s case study

Piaggio Group uses CAE to ensure a new product design’s safety and durability

The connecting rod is one of the most important components in powertrain systems, so it requires very careful structural analyses because its failure implies serious damage to the entire engine.

CASE STUDY

Cimolai Technology chooses Ansys to save design time and improve product quality

Cimolai Technology designs and produces special machines and plants for lifting, handling, transport and launching operations

Cimolai Technology explains the business benefits it has achieved since the installation in terms of time savings in planning, and design, and improvements in product quality and in delivery forecast ability.

CASE STUDY

CFD Characterization of the Ventricular Assist Device HeartAssist 5® Through a Sliding Mesh Approach

Analysis to determine possible optimizations to enhance device safety and efficacy for long-term patient use

This technical article describes how high-end numerical Computational Fluid Dynamics (CFD) simulations were applied to mimic the realistic operating conditions of a Ventricular Assist Device (VADs) and analyze its hemodynamics in order to identify potential areas for optimization of the device’s performance, safety and efficacy.

CASE STUDY

Cooling fan module road test simulation

For engine cooling, Johnson Electric offers smart Cooling Fan Modules (CFM) with best in class efficiency and power density

ptimization of the product starts with a strong correlation of the model with specifically designed tests under controlled conditions.

CASE STUDY

Strategy to optimize the independent suspension system of an off-highway, agricultural tractor

The purpose of the case study was to implement a design methodology that used multi-disciplinary simulation and an automated process to analyse thousands of product configurations and highlight vehicle performance distributions in terms of handling, comfort, and cost. This approach ensures that the best solution is always selected.

CASE STUDY

Conduct fatigue checks directly in Ansys Mechanical using SDC Verifier

Template-based design automates future routine work, and automated documentation facilitates report generation

A lot of steel structures such as cranes, heavy machinery and other equipment subjected to repetitive loading is highly likely to develop cracks or failures because of the fatigue damage. The cost of every hour of equipment downtime is usually very expensive, making it mandatory to perform residual life calculations or fatigue checks.

CASE STUDY

CFD-Driven Design of a Ventilation System for Kitchen Hoods

Optimized design achieves energy efficiency and cost containment objectives

This article presents a study that the Elica Group commissioned from EnginSoft to support it engineering team in redesigning the ventilation system of its “Tilly” kitchen hood model

CASE STUDY

Improving the efficiency of an electric arc furnace’s canopy hood

This technical article describes a numerical (transient computational fluid dynamics) simulation applied to study the suction efficiency of a canopy hood in a steel plant’s electric arc furnace with a view to increasing it.

CASE STUDY

Cost Effective High- Performance Design: Innovation is the Answer

Marelli Motori applies multiphysics simulation to cost-effectively design better, more reliable motors and generators faster

Improving efficiency while reducing cost is a very complex engineering challenge. Marelli Motori makes extensive use of CFD and FEM multiphysics simulation to do just that in the design of its electrical motors and generators.

CASE STUDY

The Structural Design of Roller Coasters

An integrated CAD-CAE procedure

Engineers will normally need to evaluate a number of different designs, only one of which will result in the final construction configuration. This is why numerical simulation plays an indispensible role in roller coaster design.

CASE STUDY

Excavators

The influence of flexibility was considered with the use of both the Reduced Flex and the Full Flex options in RecurDyn

A multibody model of an excavator was developed to calculate the loads acting on the structure and to perform static structural verifications of the different components.

CASE STUDY

Using high-fidelity FSI simulation and advanced mesh morphing to simulate and mitigate vortex-induced Vibrations

This study discusses the complex and challenging problem of controlling vortex-induced vibrations (VIV).

CASE STUDY

Simulating tomorrow's future today: Forty years of EnginSoft and counting

The text provides an in-depth account of Stefano Odorizzi’s journey in founding and growing EnginSoft, our engineering company specializing in computer simulation and modelling. Established in 1984, EnginSoft overcame early challenges, such as the high cost of computing, to emerge as a leader in simulation services, particularly in the fields of mechanical engineering and computational fluid dynamics (CFD). The narrative highlights several key milestones in the company’s history.

CASE STUDY

CFD analysis for the evaluation of the air flow within a climate control unit

Considering the value of numerical analysis for new product design

The objective of the study was to create a virtual model of Climaveneta’s new ACU171 Expanded Close Control Unit and then match the numerical results with the experimental measures.

CASE STUDY

Acoustic assessment of an electric water pump using Ansys Workbench and Multiphysics simulation

Feasibility study of a complete acoustic workflow

This technical article describes an acoustic emissions study conducted on an electric water circulation pump used for supplementary cooling or heating functions in vehicles, by the Modeling & Simulation Pumps Department of Pierburg Pump Technology

CASE STUDY

Electrifying Solutions for Motors and Generators

Marelli Motori engineers use Ansys multiphysics solutions to custom-design motors and generators to solve challenges in hydropower, cogeneration, oil and gas, civil and commercial marine transport, military applications, and ATEX applications involving motors and generators in explosive atmospheres, among other applications.

CASE STUDY

Optimizing the performance of antennas installed on avionics platforms

Rapid and accurate evaluation of platform impact on antenna radiating characteristics is vital

This article discusses the use of the Ansys HFSS SBR+ method for wave propagation analysis that is based on specific EM propagation formulations (commonly referred to as Asymptotic Methods), and which offers an effective alternative in terms of solution accuracy and computational cost. The method’s effectiveness is demonstrated in this case study that considers the analysis of an ESM sinuous antenna installed on an avionics platform.

CASE STUDY

Nautilus tech by Faber Spa: The new frontier for hoods ventilation

A Finite Element Method approach applied to product development for ventilation hoods

Faber Spa, which has designed and manufactured ventilation hoods for the past 50 years, holds a key global position both in terms of production and technology. It has achieved this position through strategic investments in research and development.

CASE STUDY

The Future of Digital Manufacturing Starts with Model-Based Definition (MBD): Enrico Boesso of EnginSoft Face to Face with Daniel Campbell of Capvidia

In a recent interview, Enrico Boesso (EnginSoft) and Daniel Campbell (Capvidia) discussed how Model-Based Definition (MBD) is transforming manufacturing by replacing traditional 2D drawings with data-rich 3D models as the "single source of truth".

CASE STUDY

Greenhouse Module for Space System

This feasibility study has been carried out to investigate and develop the characteristics of a greenhouse module for a future lunar base

This project has been coordinated by the German Aerospace Center (DLR) and it is embedded in the MELiSSA framework of ESA research projects.

CASE STUDY

Predicting the strength of composite materials using Ansys Software

Applicable from material design to product design

This technical article discusses some of the problems of using finite element method (FEM) simulation software for composite material analysis and introduces new solutions from CYBERNET with Ansys Software for solving these problems.

CASE STUDY

Whirlpool uses simulation to investigate improvements to vacuum cleaner performance

Simulation studies help Whirlpool identify the most useful design modifications to support its product objectives

This article describes how EnginSoft applied a Computational Fluid Dynamics (CFD) analysis, on behalf of Whirlpool EMEA, to simulate three different geometrical design modifications to the vacuum cleaner head to improve on a baseline performance that was modelled first.

CASE STUDY

Optimizing the shape of the M10 engine’s injector head methane circuit using RBF mesh morphing

This article is based on a collaboration between RBF Morph and AVIO to configure a numerical optimization procedure to improve the Vega E M10 engine’s performance by optimizing the methane circuit of the injector head.

CASE STUDY

The brave new world of virtual commissioning

Current market demands require new approaches to assure business imperatives are achieved

The following article explains how this new approach to the design of automated machines can enable industrial automation OEMs and system integrators to achieve these business imperatives with the assistance of industrialPhysics simulation software.

CASE STUDY

A CFD simulation of melting furnace for the production of stone wool

Simulation provides substantial information about the melter’s operating conditions

Gamma Meccanica’s R&D department is constantly researching new solutions to improve the overall performance of equipment, production capacity and reliability while developing environmentally sustainable processes and applications to benefit its customers.

CASE STUDY

Optimizing the Aerodynamic Efficiency of an Aircraft Nacelle

The optimal aerodynamic design while substantially reducing the costs

The challenge was to find the optimal aerodynamic design while substantially reducing the costs associated with traditional CFD modeling.

CASE STUDY

A History of Vortices

Detecting and mitigating critical flow structures in water pumping stations is a complex engineering task, that has always been based on experimental activities.

GE Power is a world leading supplier of solutions for power generation, from engineering to manufacturing. Detecting and mitigating critical flow structures in water pumping stations is a complex engineering task, that has always been based on experimental activities. Now GE Power can rely also on CFD modelling and on the support of EnginSoft

CASE STUDY

Interview with Diego Barone, R&D Project Leader at Vin Service

Vin Service, founded in 1976, is a world leader in dispenser technology and the first Italian manufacturer of draft-wine dispensers. Its core business is in the dispensing equipment industry and in cooling systems for beverages.

CASE STUDY

Johannesburg 2010 World Cup Stadium Roof and Facade Design

An ambitious remodeling and expansion plan for the stadium was initiated

The study analyzed these structures for strength, service and stability conditions before construction.

CASE STUDY

Optimizing the cable routing for a hyper-redundant inspection robot for harsh, hazardous environments

A multi-objective optimization framework to reduce the actuation loads and increase the payload

This article discusses a multi-objective optimization study to determine the optimal matrix for the routing of the actuating cable system in order to minimize the cable load on the robot and maximize the robot’s payload.

CASE STUDY

Improving the reliability of multibody simulation by implementing a hysteretic tyre model for radial dynamics

Multibody simulation is integral to engineering, enabling precise analysis of structural loads and dynamic behaviours in complex systems. In the context of forklifts, where tyres play a critical role due to the absence of suspension systems, accurate tyre modelling is essential. This study develops and validates a hysteretic Bouc-Wen model for the radial dynamics of solid rubber tyres to enhance simulation reliability.

CASE STUDY

Numerical applications of an Ansys-based tool to analyze hybrid metal/composite lattice structures

Computationally efficient method enables design and optimization processes of axial-symmetric lattice structures to be conducted simply and quickly

This paper, by means of presenting three application cases, provides a brief description of the capabilities of a numerical tool developed for the design and optimization of hybrid metal/composite lattice structures created with 3D printing

CASE STUDY

Filling and compression analysis of metallic powders composed of spherical particles

The efficiency of material design can be greatly improved by using FEM-based virtual material testing analysis

This article presents an example of the analysis of a powder composed of spherical particles. Since powders have a very fine heterogeneous structure, a multi-scale approach based on homogenization analysis is proposed.

CASE STUDY

Solving the chainsaw kickback problem with Maplesoft and ANSYS

Maximising chainsaw safety over the tool’s life by analysing the kickback problem and lifetime tool fatigue and performance

The avoidance or reduction of chainsaw kickback is a key safety feature for manufacturers. The challenges for engineers are to obtain more accurate analyses of the problem over the tool’s lifecycle.

CASE STUDY

Optimization techniques applied to centrifugal compressor design

Using RSM to save design time and speed time-to-market

Optimization tools, and specifically response surface methods (RSM), can be adapted very well in the design process to provide information around the design of a compressor stage. This article will cover two of the possible optimization uses: the search of optimum performance and data generation.

CASE STUDY

New solution for cost-effective electromagnetic analysis

EnginSoft’s contribution recognized in the F4E Technology Transfer Program

EnginSoft’s cost-effective solution was successfully created in collaboration with F4E’s expert teams after numerous years spent developing and testing tools, algorithms and customized interfaces in each phase of the Electromagnetic FEM analysis workflow.

CASE STUDY

A design study of a centrifuge for separating water and plastic

This paper presents the preliminary simulation study of a typical centrifuge currently produced by Gamma Meccanica. The objective of this study is to evaluate the behaviour of the centrifuge using moving particle simulation and discrete element method (MPS-DEM) simulation techniques with Particleworks 7.2.1 to gain a better understanding of phenomena that are impossible to monitor experimentally.

CASE STUDY

Ultra-Wide Band Radome CAE Optimization

Overcoming mechanical and electromagnetic challenges in refining a radome for electronic warfare

Elettronica SpA designs and produces systems for electronic warfare. Each system design is unique according to its platform and purpose. In this article, the company describes how it used CAE to approach the challenging design of a single sandwich radome.

CASE STUDY

Air Cooled Heat Exchanger Systems Performance Modeling

Model of a Liquefied Natural Gas (LNG) Plant for the simulation of the Air-Cooled Heat Exchanger Systems’ (ACHE)

EnginSoft developed a 3D CFD model of a Liquefied Natural Gas (LNG) Plant for the simulation of the Air-Cooled Heat Exchanger Systems’ (ACHE) arrays and their interaction with the wind.

CASE STUDY

Numerical analyses of the heat transfer processes of a key cooling system in the ITER reactor

Supporting the design of a critical system with realistic numerical simulations of heat radiation and conjugate heat transfer

The ITER reactor’s electron cyclotron heating and current drive (EC H&CD) system launcher requires an effective cooling system due to the strong thermal loads it supports. In supporting the design of this cooling system, NINE performed several numerical studies using the Ansys simulation tools

CASE STUDY

Fuel Injection

A multibody model was developed using RecurDyn to study the high-speed dynamic behavior of the injector during a typical work cycle

The model contains both rigid and flexible bodies: the pin was modelled using the proprietary Full Flex technology which includes a Finite Element body in the dynamic simulation.

CASE STUDY

Structural Optimization of the Drift Chamber at FermiLAB

A collaboration between EnginSoft and the Italian Institute of Nuclear Physics (I.N.F.N.)

The ultimate goal of the study was to optimize the Drift Chamber’s performance in terms of stiffness, strength and weight o be mounted on the Mu2e particle detector at FermiLAB in Chicago

CASE STUDY

Designing Versatile and Athletic Robots with CAE

This article presents an example of a proposed design optimization approach with a case study.

CASE STUDY

Using Simulation and Modeling for medical Radio Frequency design

A study demonstrating the benefits of simulation over prototyping

The growth of technology and end-user expectations is ever more important in many application areas and medical devices are at the forefront of this innovation process.

CASE STUDY

Refining the design of a spout for a laundry detergent

Particleworks enables fluid flow simulation combined with human-like behavior to improve product performance

In this case study, LION Corporation uses Particleworks to simulate fluid flow to improve the design of a new cap spout for its new HARETA brand of laundry detergent.

CASE STUDY

A new heart valve replacement procedure modeled with multiphysics simulation could eliminate the need for open-heart surgery

24% operative mortality rate of open-heart surgery for older patients drives search for less-invasive aortic valve replacement technique

Since this cannot be accurately measured in an implanted stent, manufacturers decided to use Multiphysics to simulate the process to better understand the method and to calculate the forces operating on the implant in order to improve the stent design and the surgical procedure, as described in this article.

CASE STUDY

CFD analysis of an industrial burner of a regeneration gas heater application

Using CFD analysis to save time and money in designing and testing industrial burners for the oil and gas industry

In this technical case study, EnginSoft was called in to assist in the application of Computational Fluid Dynamics (CFD) to model the flame size of a regeneration gas-fired heater for a project in Oman.

CASE STUDY

Durability and Buckling Analysis of Storage Tanks

Teknokon Machinery has developed its know-how in design and manufacturing of various types of storage tanks

By taking advantage of EnginSoft experience in Simulation Based Engineering, by means of the FEM analysis, the Durability, Structural Integrity and Buckling behavior of a new group of toxic liquid and fuel storage tanks have been investigated.

CASE STUDY

Ku-band filter design for high power space applications using Ansys simulators

This paper presents the design and first experimental results of a very compact Ku-band bandpass filter for high power satellite applications. The filter was designed and simulated using the Ansys HFSS and Mechanical simulators. Proposed as part of an ESA ARTES Advanced Technology project, the filter is based on dielectric loaded combline resonators.

CASE STUDY

RecurDyn helps ensures passenger safety in faster, higher capacity detachable chair lifts

Software facilitates dynamic studies of complex multi-body models to predict accelerations; verify, shape and size structural parts

Dynamic studies are required to predict the accelerations, verify that the cams are properly shaped, and to extract the loads to structurally size the parts.

CASE STUDY

Optimally designing an artificial lung for extracorporeal life support

A CFD-based approach

The study described in this article was designed to obtain greater insight into the gas transfer mechanism at microscopic scale using computational fluid dynamics in order to accelerate design exploration to find the optimal solution.

CASE STUDY

Structural Analysis of the Celtic Gateway Footbridge Design

A cable stayed, stainless steel footbridge connecting the port in the Welsh island of Anglesey to the town center of Holyhead

The footbridge is supported by two cable-stayed, stainless steel arches lying on inclined planes, supporting a steel deck with concrete infill.

CASE STUDY

Lime Kiln DEM Analysis with ROCKY

CAE is key to ensuring the efficiency and technical integrity of equipment and plants in the lime industry

In the lime industry, the process engineers of Cimprogretti advise on process safety, analyse and interpret laboratory and plant data and provide specialised support to ensure the technical integrity of equipment and plants.

CASE STUDY

CFD analysis for ESO’s extremely large telescope (ELT) in Chile: Wind screening performance of the dome and main structure

The Extremely Large Telescope (ELT) is a 40m-class optical and infrared telescope being built in Chile. The ELT has a complex geometry, with a rotating structure and a dome that must be protected from wind effects to ensure accurate observations. To study the wind flow within the dome, a computational fluid dynamics (CFD) model was created.

CASE STUDY

The impact of numerical analysis on the efficiency of cooker hood ventilation systems

Minimizes trial and error activities and costs and improves right-first-time results

This technical article describes how CFD analysis minimizes trial and error activities and costs and improves RFT – “right first time” – results.

CASE STUDY

Fluid Dynamics Optimization of Racing Engine Inlet Ducts at Aprilia Racing

Optimising racing engine inlet ducts using fluid dynamics

Racing engines are continuously evolved and fine-tuned to allow them to achieve extraordinary levels of performance, albeit with great complexity. However, MotoGP regulations restrict engine development by constraining some of the main design parameters.

CASE STUDY

A Great Team, Numerical Simulation and Experimental Testing

Will the customer be satisfied with the performance and the quality of the product?

Today, numerical simulation and experimental testing are used to qualify products in different stages of the development process.

CASE STUDY

Forklift Dynamics

The forklift’s wheels were represented in detail to implement a sophisticated model of the tire features

A client wanted to evaluate the dynamic performance of a new-concept forklift, so a fully-functional multibody model of the forklift was built by assembling the client’s CAD geometries.

CASE STUDY

Analysis of the behavioral characteristics of detergent powder using Rocky-Ansys Fluent two-way coupling

This analysis attempts to understand the behavior of sticky detergent powders according to flow velocity using Rocky-Ansys Fluent two-way coupling.

CASE STUDY

A natural remedy for hot-spot stresses

Using advanced mesh morphing to seamlessly perform bio-inspired structural shape optimization

This paper demonstrates how the biological growth method, studied by Mattheck in the 1990s, can be easily implemented for structural shape optimization finite element method (FEM) analyses using advanced radial basis functions (RBF) mesh morphing.

CASE STUDY

Multi-Objective Optimization of a Sailing Yacht Aluminum Mast

The optimal mast weight under specific structural strength requirements

The aim of this study was to reduce the weight of the world’s tallest aluminum mast for a new series of single mast sailing yachts manufactured by Perini Navi under the brand name Salute.

CASE STUDY

Shape Rolling of a European Standard Beam IPE Profile

A pilot study carried out by engineers from EnginSoft and Beltrame

The study allowed the engineers to estimate the shape profile geometry after each roll pass, the rolls wear and the total load and point at which the beam will bend in off-center setups.

CASE STUDY

MICAD, engineering aimed at the sea’s jewels

CAE technologies in the Marine Industry

Traditional naval architecture meets the CFD analysis with the aim to improve consolidated products reaching values in terms of performance never seen before.

CASE STUDY

The use of virtual prototyping tools in the design of Generation IV Nuclear Energy Systems

Interview with Fabrizio Magugliani, Sr. Engineer, Aero/Thermo Analytical Design, Ansaldo Nucleare SpA

Two main reasons have been the drivers for introducing and using CAE simulation technologies and mathematical modeling: safety and achieving optimal design.

CASE STUDY

Immergas: Using CAE to improve energy efficiency, reduce emissions and costs, and shorten time-to-market

Interview with engineer Luca Cavalli, from the advanced engineering team at Immergas

In this interview, engineer Luca Cavalli, of Immergas’ advanced engineering team, discusses the technical and business benefits the company has realised since first introducing Computer-Aided Engineering (CAE) technologies into its R&D department in 1997.

CASE STUDY

Trapped-vortex approach for syngas combustion in gas turbines

3D Computational Fluid Dynamics analysis reveals ideal placement for the inlets to create the energetic vortex

This technical article presents a study to design a device that operates entirely on the principle of trapped vortices that intrinsically improve the mixing of hot combustion gases with fresh mixture, a characteristic that is essential both to diluted combustion and to Moderate or Intense Low-oxygen Dilution (MILD) combustion.

CASE STUDY

Loaded tooth contact analysis and dynamic investigation of Spiral Bevel

Spiral bevel gear pairs (SBGs) play an important role in transferring power between non-parallel shafts in transmission systems. This paper presents the dynamic results of the case study investigated and illustrates nonlinear phenomena.

CASE STUDY

Dynamic response of a buried pipeline, under the action of the fall of rocks on the soil

Safety assessment of a buried pipeline potentially subject to rockfalls

Oil or gas pipelines that cover long distances pose complex design challenges. Every environment the pipeline crosses is characterized by different potential geohazards. One of the most dangerous for a pipeline is a rockfall.

CASE STUDY

Transient CFD Analysis of a Pelton Turbine

The performance evaluation to upgrade an existing hydropower plant

EnginSoft developed a Computational Fluid Dynamic (CFD) analysis methodology for the performance evaluation of a Pelton turbine

CASE STUDY

Improving the design of the Air Purification Tower using 3D CFD

The Nederman Group is a world leading supplier and developer of products and solutions within the environmental technology sector. Their latest step is the use of 3D CFD which improved the performance of their Air Purification Tower by 15%!

Nederman’s Air Purification Tower is the perfect choice if source extraction is not a satisfying option.

CASE STUDY

Integrated Simulation of Commercial Pasta Manufacturing

The Virtual Optimization PAsta production process (OPAV) research project, which resulted in a simulation model

This study was part of the Virtual Optimization PAsta production process (OPAV) research project,

CASE STUDY

Multiphase CFD Analysis of Condensation in Automotive Headlamps

A new 3D CFD multi-phase model to simulate the water condensation-evaporation processes

EnginSoft implemented a new 3D CFD multi-phase model to simulate the water condensation-evaporation processes inside automotive headlamps for Automotive Lighting, a leading supplier of quality headlights to the OEM market

CASE STUDY

Improving a coffee capsule machine’s capacity and performance using multibody simulation

Improvements achieved by optimizing laws of motion governing machine components

This technical article describes a project undertaken by OPEM to optimize and validate the laws of motion governing the moving operations of a machine that produces coffee capsules, namely the cut and weld unit, the film feeder, the conveyor and the support structure.

CASE STUDY

Preliminary thermo-mechanical design, simulation and optimization of LAD on board the eXTP space mission

This article describes the preliminary study resulting in the design solutions adopted for the LAD module’s most important thermo-mechanical drivers, which were developed and used to demonstrate compliance with the system requirements at the spacecraft level.

CASE STUDY

ISEO adopts Cetol 6σ for a global approach to dimensional management

Technical collaboration and support from EnginSoft key to achieving maximum benefit from the solution

This case study describes ISEO’s project to introduce a global dimensional management approach based on CETOL6σ that starts from the product concept phase and includes design development and prototyping and extends on to cover all other phases of production through to the finished product, with the guidance and support of EnginSoft.

CASE STUDY

How to optimize an external gear pump in highly constrained conditions

Meeting the engineering challenge of increasing efficiency while reducing costs

In this technical case study, EnginSoft assists Casappa to further refine an already-optimized standard series pump for an electrical motor and generator

CASE STUDY

Circuit Breakers

Multibody simulation is the best technology to analyze the dynamic behavior of safety circuit breakers

The premium software RecurDyn was used to simulate a Double Pole Single Throw Switch using three different modeling schemes. A comparison of the results provided useful information for the designers.

CASE STUDY

Reshaping the DEMO Tokamak’s TF Coil with high fidelity Multiphysics CAE and advanced mesh morphing

This article describes the Multiphysics optimization procedure undertaken to ensure the best compromise between electromagnetic and structural compliance for the Toroidal Field coils of the Advanced Divertor Configurations of the toroidal chamber, that holds the plasma in which the fusion reaction takes place.

CASE STUDY

Improved blast furnace performance with material load optimization

Combining modeFRONTIER with Rocky DEM to design a better deflector saves up to 130 hours of computation time

The Arvedi Group approached the University of Trieste to find a solution to the uneven distribution of material inside the hopper of their blast furnace in Trieste, Italy.

CASE STUDY

High Quality Printing with CFD

Simulation allows engineers to improve print quality, ensure operator safety and contain energy consumption

In this article, Uteco describes how it applied Computational Fluid Dynamics (CFD) to assist the design and improvement of its printing machines.

CASE STUDY

CFD study to optimize the cooling performance of a narrow specialty tractor

Numerical modelling reveals design strengths and weaknesses prior to prototype testing, saving time and money

In this technical article, a CFD study of various designs for four different specialty tractors: two brands of specialty tractors for vineyard configurations, and two brands of specialty tractors for orchard configurations, are described.

CASE STUDY

Many companies united by a common purpose: to enable people to rise

The choice to employ the ANSYS technology

Today the numerical simulation offers an important added value for dimensioning and testing of the motorbike’s chassis.

CASE STUDY

SACMI designs optimized next-generation components using automated surface sculpting

Uses Adjoint and BGM shape-modification approaches for mesh morphing

Mesh morphing has proven to be a valuable tool in parametrizing numerical models to perform shape optimization. It allows engineers to save time in generating new configurations for analysis because it does not require geometry modification and mesh re-generation.

CASE STUDY

Treating residual stresses and deformations in die castings

Virtual simulation during product and process design improves time to market and cost efficiency

This technical article illustrates the advantages of using virtual simulation to evaluate the thermal processes of die casting to reduce the formation of residual stresses and deformations in the components produced.

CASE STUDY

From saving energy to creating energy

Use pumps as turbines to generate low-cost electricity from existing piping systems

This article describes how SAER ELETTROPOMPE used Ansys CFX to transform "standard" pumps into pumps to be used as turbines.

CASE STUDY

RecurDyn easily analyses the complex dynamics of a musical box

Analysis includes highly flexible bodies and extended contacts with their surfaces

This is a classic scenario that exploits the best features of RecurDyn software, such as the Full-Flex and the Geo-Contact technology.

CASE STUDY

Face to face with Pietro Del Negro Senior CAE engineer at Ricardo

How Ricardo predicts the life of motorcycle components

In this article, Del Negro explains how Ricardo is developing solutions to support its customers to predict the lifecycle of motorcycle components, using finite element analysis (FEA) and fatigue analysis.

CASE STUDY

Tolerances analysis on a nitrogen spring

EnginSoft models technical product modifications to enable Special Springs to satisfy a customer request at the minimum cost

Special Springs commissioned EnginSoft’s engineers to calculate the production cost repercussions of a technical product modification requested by an important customer.

CASE STUDY

Cross Validation of the Final Design for the Margaret Hunt Hill Bridge

The bridge designed by the world famed architect Santiago Calatrava

The bridge represents an example of a cable stayed mixed steel-concrete structure, where the stay cables are asymmetrically connected to the center of the deck and to the top of the central transverse steel arch.

CASE STUDY

Digitizing a process to standardize the analysis and evaluation of windshield wiper performance

TAE SUNG collaborates with DY Auto to develop dedicated software

This technical article describes a project that was undertaken by TAE SUNG Software and Engineering, in collaboration with DY AUTO in Korea, to establish a computerized process to conduct three-dimensional real-scale analysis of any of the three types of windshield wiper currently in use, and to establish a specific standard for evaluating wiper performance.

CASE STUDY

Agricultural equipment suppliers use CAE to improve product performance, safety and desirability

CAE technologies also reduce design and testing times, and design costs

This case study describes how the company’s R&D team used ANYSYS and Spaceclaim to conduct Finite Element Method analyses to refine the design of a new model of a sprayer boom used by farmers to distribute phytosanitary products over fields for crop protection.
